The 64 Frame sealless pump, featuring a brushless DC motor, boasts an impressive design life of 60,000 hours and can efficiently extract 26 gallons of ethylene glycol and water mixture every minute.
This pump is exclusively available in 24 VDC, making it an excellent choice for robust transportation needs, such as transit buses, construction and mining vehicles, heavy-duty agricultural equipment, and various on- and off-highway vehicles.
Pump Features
Sealless design is leak proof; pump is magnetically coupled
to motor
Motor is removable from pump without draining system
Environmentally resistant to hot-water spray, salt, fog,
shock and vibration
Cast brass pump designed for heavy-duty applications
Motor Features
24 VDC model only
Brushless motor design provides maintenance-free
operation
Rare-earth magnets provide high efficiency and low current
draw
“O” ring sealed for harsh operating environment
Reverse polarity and surge protected
Heavy-duty construction required for transit bus and
construction equipment
